FITSAT-1

FITSAT-1 (NIWAKA)

5.8GHz high speed transmitterWe have developed a 5.8GHz high speed transmitter for artificial satellites. It consists of an exciter module with a 115.2kbps FSK modulator and a liner amplifier which amplifies a 10mW signal to 4W. We are now developing a small artificial satellite named FITSAT-1. It also has the nickname “NIWAKA”. The shape is a 10cm cube, and the weight is 1.33kg. The main mission of this satellite is to demonstrate the high speed transmitter developed. It can send a jpeg VGA-picture(480×640) within 6 seconds.

Block diagram

FITSAT-1 Block Diagram

Optical Experiment

FITSAT-1 Takushi TanakaNIWAKA has another experimental mission to test the possibility of optical communication by satellite. It will actually twinkle as an artificial star.

NIWAKA’s high power LEDs will be driven with 100W pulses to produce extremely bright flashes. These, we hope, will be observable by the unaided eye or with small binoculars.

NIWAKA will be launched from the International Space Station around September 2012 as shown here.

Light communication

FITSAT-1 Leds sending Morse CodeFITSAT-1, will write messages in the night sky with Morse code, helping researchers test out optical communication techniques for satellites. After its deployment from the orbiting lab, the cubesat’s high-output LEDs will blink in flash mode, generating a Morse code beacon signal. The flashing light from FITSAT-1 will be received by a Fukuoka Institute of Technology ground station that has a telescope and a photo-multiplier device linked to an antenna.

Orbital parameters

Name                    FITSAT-1 (NIWAKA)
NORAD                   38853
COSPAR designator       1998-067-CP
Inclination             51.649
RA of A. Node           259.821
Eccentricity            0.0014708
Argument of Perigee     158.042
Revs per day            15.51679488
Period                  1h 32m 48s (92.80 min)
Semi-major axis         6 790 km
Perigee x Apogee        402 x 422 km
BStar (drag term)       0.000493810
Mean anomaly            202.121

Downlink

437.250 MHz CW Beacon
437.445 MHz FM 1k2 AX25 remote command
5.840.00 GHz High speed data

Uplink

437.445 MHz FM 1k2 AX25 remote command

Call

JG6YEW

Status

Decayed. Launched from ISS on October 4th, 2012 and active.

Telemetry

The beacon signal is a standard Morse code CW signal. The signal consists of call sign and telemetry data.

QSL Card

FitSAT-1 QSL


Homepage and other references:

http://www.fit.ac.jp/~tanaka/fitsat.shtml
